1. Parameter Specifications

• Power Supply: The AFIN - 01C 4110276EE operates on a 24V DC power supply, with a relatively low power consumption of about 5 - 8W. This energy - efficient design makes it suitable for long - term continuous operation.
• Input/Output Configuration:
• Digital Inputs: It is equipped with 8 digital inputs. These inputs can accept signals from various digital sensors such as proximity sensors, limit switches, and photoelectric sensors. The input voltage range is 5 - 24V DC.
• Digital Outputs: There are 4 digital outputs. Each output can drive a load with a maximum current of 0.5A, which is suitable for controlling small - scale relays, solenoids, or indicator lights.
• Analog Inputs: There are 2 analog inputs. They can receive signals in the ranges of 0 - 10V or 4 - 20mA, with a 10 - bit resolution for basic analog quantity measurement, like temperature or pressure.
• Analog Outputs: 1 analog output is available, capable of outputting signals in the same ranges as the analog inputs for simple analog control tasks.
• Communication Interface: It supports an RS - 485 serial communication interface with the Modbus RTU protocol. This enables seamless data exchange with other Modbus - compatible devices and control systems.

2. Applications

• Industrial Automation: In industrial manufacturing, the AFIN - 01C 4110276EE can be used to control and monitor simple production processes. For example, it can manage the operation of a single machine or a small group of machines on a production line. It can control the start and stop of a conveyor belt based on the detection of products by a proximity sensor.
• Building Automation: In commercial or residential buildings, it can be involved in basic building management tasks. It can control the lighting in a specific area or adjust the operation of a small - scale ventilation fan according to the environmental conditions detected by sensors.
• Agricultural Automation: In agricultural settings, it can be used to control simple irrigation systems. By measuring the soil moisture level through an analog sensor, it can control the operation of a water pump via a digital output.

3. Weight and Dimensions

• Weight: The module weighs about 0.1 kg, which is very light and easy to install and handle.
• Dimensions: The overall dimensions are: length - 60mm, width - 40mm, height - 10mm. Its compact size allows for installation in tight spaces, such as inside small control boxes or on equipment panels.

4. Features

• Modbus Compatibility: The support for the Modbus RTU protocol on the RS - 485 interface simplifies integration with other industrial devices and control systems. This enables easy system expansion and data sharing, enhancing the overall functionality of the industrial control network.
• Cost - Effective Solution: With its relatively simple configuration and affordable components, the AFIN - 01C 4110276EE offers a cost - effective option for small - scale control and monitoring applications. It is suitable for small businesses or projects with budget constraints.
• User - Friendly Configuration: It has a straightforward configuration process. Even users with limited technical knowledge can easily understand and implement the configuration, reducing the time and effort required for system setup.

5. Stability and Reliability

• Robust Construction: The module is housed in a durable plastic enclosure that provides protection against dust, moisture, and minor mechanical vibrations. This ensures stable operation in normal industrial and non - industrial environments, minimizing the risk of malfunctions due to external factors.
• Fault - Tolerant Design: It is designed with built - in protection mechanisms such as over - current protection for the digital outputs. These features safeguard the module from electrical faults and extend its service life, reducing maintenance costs.
• Quality Components: The use of high - quality electronic components and strict quality control during manufacturing ensure long - term reliability and consistent performance.

6. Real - world Examples

• Small - scale Woodworking Workshop: In a small - scale woodworking workshop, the AFIN - 01C 4110276EE controls the operation of a small sawing machine. It receives signals from a limit switch to detect the position of the wood and controls the power supply to the saw via a digital output.
• Residential Flower Garden: In a residential flower garden, it controls the watering system. It measures the soil moisture through an analog sensor and activates the water pump via a digital output when the soil is dry, ensuring proper watering of the flowers.
