1. Parameter Specifications

• Power Supply: The TP857 3BSE030192R1 typically operates on a 24V DC power supply. The power consumption is relatively low, around 10 - 15W, which is energy - efficient for long - term operation.
• Input/Output Configuration:
• Digital Inputs: It has 16 digital inputs. These inputs can receive signals from various digital sensors such as proximity sensors, limit switches, and photoelectric sensors. The input voltage range is 5 - 24V DC.
• Digital Outputs: There are 8 digital outputs. Each output can drive a load with a maximum current of 1A, suitable for controlling small - to - medium - sized relays, solenoids, or indicator lights.
• Analog Inputs: There are 4 analog inputs. They can accept signals in the ranges of 0 - 10V or 4 - 20mA, with a 12 - bit resolution for measuring physical quantities like temperature, pressure, and flow.
• Analog Outputs: 2 analog outputs are available, capable of outputting signals in the same ranges as the analog inputs for precise analog control.
• Communication Interface: It supports an Ethernet interface for high - speed data transfer and integration into industrial networks. It also has an RS - 485 port with Modbus RTU support for communication with other Modbus - compatible devices.

2. Applications

• Industrial Automation: In industrial manufacturing plants, the TP857 3BSE030192R1 can be used to control and monitor production processes. For example, it can manage the operation of conveyor belts, control the speed of motors, and monitor the status of sensors on the production line to ensure smooth production.
• Building Automation: In commercial or residential buildings, it can be applied to control building systems such as HVAC (Heating, Ventilation, and Air Conditioning) systems, lighting systems, and access control systems. It can adjust the temperature, lighting intensity, and door access according to the environmental conditions and user requirements.
• Process Monitoring in Utilities: In water treatment plants or power generation facilities, it can monitor process parameters such as water flow, pressure, and temperature, and control the operation of pumps and valves accordingly.

3. Weight and Dimensions

• Weight: The unit weighs approximately 0.6 kg, which is relatively light and easy to install and handle.
• Dimensions: The overall dimensions are: length - 150mm, width - 100mm, height - 30mm. Its compact size allows for installation in limited spaces, such as in control cabinets.

4. Features

• High - speed Communication: The Ethernet interface enables fast data exchange, allowing for real - time monitoring and control of industrial processes. The Modbus RTU support on the RS - 485 port provides flexibility for communication with legacy devices.
• Flexible I/O Configuration: The combination of digital and analog inputs and outputs offers flexibility in system design, allowing users to customize the configuration according to specific application needs.
• User - friendly Setup: It has an intuitive configuration process, which can be easily understood and implemented by technicians and operators, reducing the time and effort required for system commissioning.

5. Stability and Reliability

• Robust Design: The device is housed in a durable plastic enclosure that provides protection against dust, moisture, and minor mechanical vibrations. This ensures stable operation in normal industrial environments.
• Fault - Tolerant Mechanisms: It is equipped with built - in protection functions such as over - current protection, short - circuit protection, and over - voltage protection, safeguarding the device from electrical faults.
• Quality Assurance: Through strict quality control during manufacturing and the use of high - quality components, the TP857 3BSE030192R1 offers long - term reliable operation.

6. Real - world Examples

• Automotive Parts Manufacturing: In an automotive parts manufacturing plant, the TP857 3BSE030192R1 controls the operation of a stamping machine. It receives signals from sensors to monitor the position of the stamping die and controls the hydraulic system of the machine via digital outputs, ensuring accurate stamping operations.
• Residential Apartment Complex: In a residential apartment complex, it is used in the building management system. It controls the lighting in the corridors and common areas based on the detection of human presence by sensors, and adjusts the temperature of the HVAC system according to the ambient temperature, saving energy and improving the living environment.
