1. Parameter Specifications

• Power Supply: The PFTL301E 1.0 KN typically operates on a 24V DC power supply. The power consumption is relatively low, around 5 - 8W, ensuring energy - efficient operation.
• Load Capacity: As indicated by the model, it has a rated load capacity of 1.0 kN. It can accurately measure forces within this range.
• Output Signal: It provides an analog output signal, usually in the range of 0 - 10V or 4 - 20mA, which is proportional to the applied force. The signal has a high resolution, often with 12 - bit or better, allowing for precise measurement and control.
• Accuracy: The accuracy of the force measurement is relatively high, with an error typically within ±0.5% of the full - scale value. This ensures reliable and precise force monitoring.

2. Applications

• Industrial Manufacturing: In industrial production lines, it can be used for force monitoring in processes such as pressing, stamping, and assembly. For example, in a stamping process, it can measure the force applied by the stamping machine to ensure that the force is within the appropriate range, thereby guaranteeing product quality.
• Material Testing: In material testing laboratories, it can be used to test the mechanical properties of materials. By applying a controlled force to the material and measuring the corresponding force values, it helps to determine the strength and other properties of the material.
• Robotics and Automation: In robotic systems, it can be installed on robotic arms or grippers to measure the gripping force. This enables robots to handle objects with appropriate force, preventing damage to the objects.

3. Weight and Dimensions

• Weight: The unit weighs approximately 0.3 kg, which is relatively light and easy to install and integrate into different systems.
• Dimensions: The overall dimensions are length - 80mm, width - 40mm, height - 30mm. Its compact size allows for installation in limited - space environments.

4. Features

• High - precision Measurement: With high accuracy and resolution, it can provide precise force measurement data, which is crucial for applications requiring accurate force control.
• Easy Installation: Its compact size and relatively light weight make it easy to install on various equipment and structures. It can be quickly integrated into existing systems.
• Analog Output Compatibility: The analog output signal is a common standard in industrial control systems. This allows for easy connection and communication with other control devices such as PLCs and data acquisition systems.

5. Stability and Reliability

• Robust Construction: The PFTL301E 1.0 KN is housed in a durable metal or high - strength plastic enclosure that provides protection against mechanical shocks, vibrations, and environmental factors such as dust and moisture. This ensures stable operation in industrial environments.
• Long - term Calibration Stability: It has good long - term calibration stability, which means that the measurement accuracy remains relatively constant over time. This reduces the need for frequent recalibration and maintenance.
• Quality Assurance: Through strict quality control during manufacturing, it meets high - quality standards and offers reliable performance.

6. Real - world Examples

• Automotive Parts Manufacturing: In the production of automotive engine components, the PFTL301E 1.0 KN is used to monitor the force during the assembly of pistons. By accurately measuring the assembly force, it ensures that the pistons are installed correctly, improving the performance and reliability of the engine.
• Consumer Electronics Assembly: In the assembly of mobile phones, it is installed on the robotic grippers. The grippers use the force measurement data provided by the sensor to pick up and place delicate components such as circuit boards with the appropriate force, reducing the risk of component damage during the assembly process.
